Tesla Model X: Controls

Controls - Overview

Touch Controls on the bottom corner of the touchscreen to control features and customize Model X to suit your preferences. The Controls screen appears over the map. Touch an option on the Controls screen to display the various settings and options associated with the chosen option. Swipe to close.

NOTE: You can also access Controls by touching anywhere on the side of the touchscreen closest to the driver and swiping open.

When an information icon displays beside a specific setting, touch it to display a popup that provides helpful details about the associated setting.

NOTE: Many vehicle controls, settings, and preferences (such as climate, media, and navigation) can be adjusted hands-free using voice commands (see Voice Commands).

1. List of available settings. When you select an item from this list, its associated settings display on the right side of the screen.
2. Settings area. The options available for the chosen settings display here, and are described next.

If the touchscreen is unresponsive or demonstrates unusual behavior, you can restart it (see Restarting the Touchscreen).

Shortcuts and Frequently Used Settings

When you touch Controls, the touchscreen displays the following shortcuts and frequently used settings:

1. Create and access driver profiles
2. Display alerts and access settings for HomeLink, Bluetooth and networks
3. Quick access to opening and closing doors and trunks
4. Commonly used controls

Pedals & Steering

Acceleration Adjust the amount of acceleration. Chill limits acceleration for a slightly smoother and gentler ride, whereas Sport provides the normal level of acceleration. (See Acceleration Modes).

NOTE: When Chill is selected, Chill displays on the touchscreen above the driving speed.

Drag Strip Mode: Preconditions the vehicle for improved performance in short distance racing (see Drag Strip Mode).

Steering Mode: Adjust the amount of effort required to turn the steering yoke (see Adjusting Steering Effort).

Apply Brakes When Regenerative Braking Is Limited: Choose if you want the regular braking system to automatically engage whenever regenerative braking is unavailable or limited (for example, the Battery is cold or fully charged). When enabled and you release your foot from the accelerator pedal when regenerative braking is limited, the braking system engages to provide the same amount of deceleration you experience when regenerative braking is available. This results in consistent deceleration regardless of the state of the Battery. See Regenerative Braking.

Auto Shift out of Park: Turn on if you want Model X to automatically choose the initial drive mode (Drive or Reverse). See Shifting.

Automatic Turn Signals: If set to Auto Cancel, turn signals cancel automatically when Model X detects completion of maneuvers such as merges, lane changes, and forks in the roadway (unless you override this by pressing and holding when you engage the turn signal). If set to Off, you must cancel turn signals after these types of maneuvers by pressing the turn signal button (see Turn Signals).

Slip Start: Turn on to allow wheels to spin (see Traction Control).

Trailer Mode: Enable Trailer Mode before towing a trailer (see Towing and Accessories).

Suspension

Adjust the settings associated with the air suspension system. You can adjust the Ride Height (helpful for increasing ground clearance on steep driveways, etc.) and you can optimize ride and handling by adjusting settings for Adaptive Suspension Damping. See Air Suspension.

NOTE: To raise the suspension to High, you can also touch the Raise Suspension shortcut on the main Controls screen, instead of displaying all Suspension settings.

Charging

View charging status and adjust settings related to charging Model X (see Charging Instructions).

Autopilot

NOTE: Depending on market region, vehicle configuration, options purchased, and software version, your vehicle may not be equipped with all Autopilot features described below

Customize how some of the Autopilot features operate to provide a safer and more convenient driving experience. See About Autopilot for an overview of Autopilot components and features.

• Cruise Follow Distance: Adjust the following distance you want to maintain between Model X and a vehicle traveling ahead of you when using Traffic-Aware Cruise Control see Adjust the Following Distance).
• Autosteer (Beta): Turn on the feature that provides automatic steering in addition to Traffic-Aware Cruise Control (see Autosteer).
• Autosteer Activation: Choose whether you want Autosteer to activate when you Single Click the right scroll button on the steering yoke. If you choose Double Click, a single press activates Traffic-Aware Cruise Control and you must press the scroll button twice in quick succession to activate Autosteer.

NOTE: To use Traffic-Aware Cruise Control independently of Autosteer, set your preferences to Double Click.

• Navigate on Autopilot (Beta) (if equipped): Navigate on Autopilot automatically exits at off -ramps and interchanges based on your navigation route and can also make lane changes designed to prepare for exits and minimize the driving time to your destination. Touch Customize Navigate on Autopilot to specify how you want Navigate on Autopilot to operate, such as whether you want it to automatically enable at the start of every trip, how you want it to perform lane changes, etc. (see Navigate on Autopilot).

NOTE: Navigate on Autopilot is not available in all market regions.

• Traffic Light and Stop Sign Control (Beta) (if equipped): Turn on if you want Model X to automatically stop at traffic lights and stop signs when using Traffic-Aware Cruise Control or Autosteer (see Traffic Light and Stop Sign Control).
• Full Self-Driving Visualization Preview (if equipped): Display more details about the roadway and its surroundings, such as road markings, stop lights, objects (such as trash cans and poles), etc.
• Summon (Beta) (if equipped): Automatically park and retrieve Model X from outside the vehicle (see Summon).

  Customize Summon: Determine the bumper clearance, distance, amount of side clearance, and whether Summon requires continuous press to operate (the ability to disable continuous press is not available in all market regions).

  Standby Mode: Use Standby Mode to eliminate the delay that occurs when Smart Summon (if equipped) is starting up.

• Set Speed: When you engage Traffic-Aware Cruise Control or Autosteer, choose whether you want the initial cruising speed set to the Speed Limit or your Current Speed (see Traffic-Aware Cruise Control).
• Off set: When set to cruise at the speed limit, you can choose a Fixed off set, in which the speed is adjusted by a specific number of mph (km/h) on all roads, or a Percentage off set, in which the speed adjustment varies depending on the detected speed limit of the road.
• Blind Spot Camera (if equipped): When ON, the touchscreen displays the view from the corresponding side repeater camera whenever you engage a turn signal to change lanes. See Blind Spot Camera and Collision Warning Chime.
• Blind Spot Collision Warning Chime (if equipped): Choose if you want a chime to sound when a vehicle is in your blind spot and a possible collision is detected (see Blind Spot Camera and Collision Warning Chime).
• Speed Limit Warning: Choose the type of warnings, if any, you receive if driving speed exceeds the detected speed limit (see Speed Assist).
• Speed Limit: Choose if you want Speed Limit Warning to use a relative or an absolute speed limit (see Speed Assist). If you choose a relative speed limit, you can specify an Off set to be alerted only when you exceed the speed limit by the specified off set amount.
• Lane Departure Avoidance: Choose if and how you want the steering yoke to respond if a front wheel passes over a lane marking when the associated turn signal is off (see Lane Assist).
• Forward Collision Warning: Choose if and when Model X displays visual and audible warnings in situations when there is a high risk of a frontal collision (see Collision Avoidance Assist).
• Emergency Lane Departure Avoidance (if equipped): When enabled, Model X attempts to prevent a potential collision with an object in an adjacent lane by steering the vehicle back into your driving lane in emergency situations (see Emergency Lane Departure Avoidance).
• Automatic Emergency Braking: Choose if you want Model X to automatically apply braking when a frontal collision is imminent (see Collision Avoidance Assist).
• Obstacle-Aware Acceleration: Choose if you want acceleration to be automatically reduced in situations where Model X is stopped (or moving slowly) and you accelerate toward a detected obstacle (see Obstacle-Aware Acceleration).
• Traffic-Aware Cruise Control Chime: If on, a chime sounds when you engage or cancel Traffic-Aware Cruise Control.
• Green Traffic Light Chime (if equipped): In Canada and U.S.: If on, a chime sounds when you are waiting at a red traffic light and the light turns green.

Locks

Keys: You can see all the keys used for Model X and their associated driver profiles. You can add, delete, and change the driver profile associated with each key (see Driver Profiles).

Window Lock: Locks the rear window switches.

Child Lock: If on, safety locks prevent the rear doors from being opened from inside the vehicle.

Walk-Away Door Lock: If on, doors automatically lock when you walk away from the vehicle carrying your key fob or phone key (see Walk-Away Door Lock).

Driver Door Unlock Mode: Driver Door Unlock Mode will only unlock the driver's door when first unlocking the vehicle.

Unlock on Park: If on, doors automatically unlock when you engage Park (see Unlock on Park).

Car Left Open Notification : Choose whether you want Model X to send a notification to your Tesla mobile app if your car remains open for over approximately 10 minutes after you have left:

• Off: You are not notified if you leave Model X open.
• Doors: You are notified only if a door or trunk is left open.
• Doors & Windows: In addition to being notified if a door or trunk is left open, you are notified if Model X is locked and a window is left open.

Touch Exclude Home to disable the notification when Model X is parked at the location you set as Home in your Favorites list (see Home, Work, and Favorite Destinations).

NOTE: To use the Car Left Open Notification, the mobile access setting must be turned on (Controls > Safety > Allow Mobile Access).

NOTE: Notifications are not sent when Model X is in Camp Mode or if Tesla Theater (if equipped) is active.

Falcon Door Height: If set to AUTO, falcon wing doors open fully, taking into consideration any remembered location-based heights, and assuming an obstacle is not detected. If set to LOW, falcon wing doors open partially, further protecting occupants and the vehicle's interior from inclement weather conditions.

Automatic Doors: If on, the driver's door opens whenever you approach Model X and the key is detected. The driver's door also opens when you double-click the key and the passenger door opens with a subsequent double-click. If not enabled, the door (or doors) unlock, but you'll need to open the driver's door manually.

Close All With Key Fob: If on, a single-click of the key fob's lock/unlock button closes and locks all doors (and the rear trunk). If off, you must triple-click the button.

Lock Confirmation Sound: If on, a soft horn sounds whenever Model X locks or unlocks (see Walk-Away Door Lock).

Close Windows on Lock: If on, all windows automatically close when you lock Model X.

Lights

Control interior and exterior lights. See Lights.

NOTE: You can also control the exterior headlights by touching the high beam headlights button on the left side of the steering yoke and then choosing an option using the touchscreen. See High Beam Headlights.

Display

• Appearance: Customize the display to be Dark or Light. When set to Auto, the brightness changes automatically based on ambient lighting conditions.
• Brightness: Drag the slider to manually control the brightness level. If Display Mode is set to Auto, the touchscreen further adjusts based on both the ambient lighting conditions and your brightness preference. Model X remembers your chosen brightness preference and adjusts the touchscreen accordingly.
• Screen Clean Mode: When enabled, your touchscreen darkens and temporarily disables to facilitate cleaning. Follow the onscreen instructions to exit Screen Clean Mode.
• Touchscreen Language: Select the language that the touchscreen displays.

NOTE: Model X must be in Park to change the language. When you change the language, you experience a brief delay as Model X shuts down and restarts the touchscreen.

• Voice Recognition Language: Choose the language to be used for voice commands.
• Voice Navigation Language: Choose the language that the navigation system uses for spoken instructions.

NOTE: For languages that require a download, select the language in the dropdown list to initiate the download (Wi-Fi connection required).

• Lock Rear Display: Lock access to the rear touchscreen.
• Time: Choose to display time in either 12 or 24 hour format.
• Energy Display: Choose to display remaining energy and charging units as either a percentage of battery energy remaining, or as an estimate of the distance you can drive.

NOTE: When anticipating when you need to charge, use energy estimate as a general guideline only. Many factors have an impact on energy consumption. See Factors Affecting Energy Consumption.

• Distance: Choose to display range using miles or kilometers.
• Temperature: Choose to display temperature using Fahrenheit or Celsius.
• Tire Pressure: Choose to display tire pressures using BAR or PSI.

Trips

View the odometer and view and reset up to two trip meters that summarize how far you have driven (see Trip Information).

Navigation

Customize how the navigation system works:

• Navigation Volume: Increase or decrease the volume of spoken navigation instructions by touching - or +, respectively. Fully decreasing the volume mutes the instructions. You can also mute navigation instructions when a navigation route is active by touching the volume icon on the turn-by-turn direction list.

NOTE: This volume setting applies only to the navigation system's spoken instructions. It does not change the volume of media player and phone calls.

• Automatic Navigation: Enable if you want Model X to automatically initiate a navigation destination when you get in your vehicle. Destinations are predicted based on commonly driven routes, time of day, and calendar entries (see Automatic Navigation).
• Trip Planner (if available in your market region): Use Trip Planner to plan your driving and add stops at superchargers if charging is needed to reach a destination to which you are navigating (see Trip Planner).
• Online Routing: When selected, Model X can automatically reroute you to a navigation destination to avoid delays (see Online Routing ).
• Avoid Ferries: When on, navigation routes avoid the use of ferries.
• Avoid Tolls: When on, navigation routes avoid the use of tolls.
• Use HOV Lanes: When on, navigation routes include the use of High Occupancy Vehicle (HOV) lanes. This is particularly useful when using Navigate on Autopilot, if equipped (see Navigate on Autopilot). You are responsible for ensuring Model X is eligible to use HOV lanes.

NOTE: You can also display these navigation settings by touching the settings icon on the map (see Maps and Navigation).

Safety

Allow Mobile Access: Allow your Tesla mobile app to access your Model X (see Mobile App).

NOTE: To disable Allow Mobile Access, you must enter your Tesla account credentials.

Parking Brake: Manually apply and release the parking brake (see Parking Brake).

Power Off: Manually power off Model X (see Powering Off).

Sentry Mode: When enabled, cameras and sensors remain powered on and ready to record suspicious activity whenever Model X is locked and in Park. See (Using Sentry Mode).

Third Row Easy Entry: If your Model X is equipped with monopost seats and a third row, a third row ingress button is located on the backrest of each outboard monopost seat in the second row. This button makes it easy for passengers to enter and exit the third row seating positions. Use this setting to choose how you want the button to work (see Monopost Seats).

View Live Camera via Mobile App (if equipped): Enable to see a live video feed of your vehicle's surroundings from the mobile app (see Using Sentry Mode).

Dashcam (if equipped): When enabled, cameras can record and save video footage of the surrounding roadway (see Using Dashcam). Customize Dashcam by selecting:

• Auto: Dashcam automatically saves a recording to the USB flash drive (if available and installed) in situations where Model X detects a safety event, such as a collision or airbag deployment.
• Manual: You must touch the Dashcam icon to save a recording of the most recent 10 minutes of driving to the USB flash drive.
• Off: Dashcam is disabled until you select Auto or Manual.
• On Honk: When you press the horn, Dashcam saves a recording of the most recent 10 minutes of driving to the USB flash drive.

Delete Dashcam Clips: Deletes all Dashcam and Sentry Mode footage, including recent and saved clips.

Format USB Drive (if equipped): If a USB flash drive is inserted into a front USB port, touch to format the flash drive to allow Model X to save video recordings using Dashcam, Sentry Mode, if equipped (see USB Drive Requirements for Recording Videos).

Park Assist Chimes: If on, a beep sounds when Model X approaches an object while parking (see Park Assist).

Joe Mode: If on, Joe Mode lowers the volume of your vehicle's chimes, except for turn signals.

NOTE: Joe Mode may not be available at delivery.

Security Alarm (if equipped): Enable the security alarm (see Safety & Security Settings).

Tilt/Intrusion: If your vehicle is equipped with the security package, a battery-backed siren sounds in situations where Model X detects motion inside the cabin, or is moved or tilted (for example, with a tow truck or jack). See Tilt/Intrusion (if equipped).

PIN to Drive: Increase security by preventing Model X from being driven until a 4-digit PIN (Personal Identification Number) is entered (see PIN to Drive).

Glovebox PIN: For additional security, protect glovebox contents using a 4-digit PIN (see Glovebox PIN).

Cabin Overheat Protection: Reduce the temperature of the cabin in extremely hot ambient conditions for a period of up to twelve hours after you exit Model X (see Cabin Overheat Protection). Cabin Overheat Protection stops operating after 12 hours, or when the energy remaining in the Battery drops to 20%, whichever occurs first.

Active Road Noise Reduction: Specify if and how you want Active Road Noise Reduction to operate (see Active Road Noise Reduction).

Service

Owner's Manual: View the onscreen Owner's Manual. A new version of the onscreen owner's manual is typically provided with every software update and therefore contains more recent information that those provided by Tesla elsewhere (for example, via the web).

Car Wash Mode: Enable before using a car wash to ensure all doors and windows are closed, and all chimes are turned off. See Car Wash Mode.

Adjust Headlights: Make adjustments to the level of the headlights.

CAUTION: Headlights should only be adjusted by Tesla Service.

Towing: Prepare Model X to be transported by keeping it in Neutral (with the parking brake disengaged), when you exit. See Instructions for Transporters.

Wheel Configuration : Update your vehicle's wheel configuration if you are installing new wheels or swapping them for different ones.

CAUTION: Changing your vehicle's wheel configuration can impact range estimates, tire pressure warnings, and vehicle visualization. See Tire Care and Maintenance.

WARNING: Tesla is not liable for damage caused by using wheels not approved by Tesla.

Notifications : Display a list of notifications that have recently appeared on your vehicle.

Camera Calibration (if equipped): Clear the existing calibration of Autopilot cameras to reset the stored camera positions and angles. Once calibration is cleared, you must drive to calibrate the cameras. See Drive to Calibrate Cameras for more information.

Factory Reset: Erase all personal data (saved addresses, music favorites, HomeLink programming, etc.) and restore all settings to their factory defaults. This is useful when transferring ownership of Model X. Before erasing, you must enter the credentials for your Tesla account.

Jack Mode: Disables self-leveling of the air suspension system.

WARNING: The air suspension system causes Model X to self-level, even when powered off. Therefore, when transporting or lifting, you must engage Jack Mode to disable self-leveling (see Instructions for Transporters and Jacking and Lifting).

Wiper Service Mode: Turn on to provide easy access to wiper blades (see Wiper Blades and Washer Jets).

Software

Learn more about your Model X and the status of software updates:

• Get more information about your Model X such as the VIN, vehicle name, and odometer. Touch Additional vehicle information to display a list of the various options your vehicle is equipped with.
• View your current software version, map version, and release notes.
• View and install new software updates. Model X must be connected to Wi-Fi to update the software.
• Customize how often you want to receive software updates by touching Software Update Preferences (see Software Update Preferences).
• Data Sharing: Allow sharing cabin camera analytics with Tesla to help improve safety features (see Cabin Camera).

To further personalize Model X, you can name it. Touch Controls > Software > Name Your Vehicle located on the right side of the screen below the image of your Model X. If your Model X has already been named, its name displays instead and you can simply touch the existing name to change it. Enter the new name in the popup, then touch Save. The name of your Model X also appears in your Tesla mobile app.

Erasing Personal Data

You can erase all personal data (saved addresses, music favorites, HomeLink programming, etc.) and restore all customized settings to their factory defaults. This is useful when transferring ownership of Model X. Touch Controls > Service > Factory Reset. Before erasing, Model X verifies your credentials by prompting you to enter the user name and password associated with your Tesla account.
